Home page >Products >Power Distribution Products >Power Supply >Voltage Regulator >TSGC/TSGC2 Series Three-Phase Contact Voltage Regulators
This product is formed by three single-phase contact voltage regulators connected using the "Y"-shaped method; install the carbon brush holder on the same central shaft, turn the rotating shaft to drive three coaxial carbon brushes, making the brush slide along the surface of the coil; when changing the electric brush contact position, the primary and secondary turns ratios of the transformer, so that the output voltage can be adjusted smoothly and steplessly within the voltage regulation range.
